iPhone Manufacturing Facility Integrated MEPF BIM Coordination
Delivered Full Integrated MEPF BIM Coordination for Precision Electronics Manufacturing Facility – Cleanroom Compliant
Project Overview
iPhone Manufacturing Facility – Integrated MEPF BIM Coordination
This project involved a precision electronics manufacturing facility developed for advanced iPhone production within a highly controlled cleanroom environment. As part of the industrial and electronics manufacturing sector, the project required full integrated MEPF BIM coordination to ensure seamless collaboration between all building services. Using Autodesk Revit and Autodesk Navisworks, our team coordinated four major disciplines including HVAC, Electrical, Fire Fighting, and Plumbing systems. The BIM coordination process focused on clash-free service routing, optimized utility distribution, and efficient space management to support the complex requirements of cleanroom manufacturing operations while improving construction accuracy and project execution efficiency.
The Challenge
What made this project complex
The facility required fully coordinated MEPF systems inside a precision cleanroom environment, where routing space was highly restricted and installation tolerances were extremely tight.
Key challenges included:
Dense ceiling and utility zones
Cleanroom compliance requirements
Zero tolerance for field clashes
Complex machine utility integration
Fast-track industrial project delivery
Our Scope of Work
Our Scope of Work Project Complex
HVAC Systems Coordination
Developed and coordinated:
• Supply air systems
• Return air systems
• Exhaust systems
• Rectangular duct routing
• Machine exhaust systems
Utility & Compressed Air Systems
Delivered:
• Compressed air distribution
• Utility routing for production machinery
• Equipment interface coordination
Fire Fighting Systems
Designed and coordinated:
• Below-duct sprinkler systems
• Roof-level sprinklers
• Fire hydrant networks
Plumbing Systems
Integrated:
• Chilled water
• Hot water
• Wastewater
• Raw water
• Domestic water
• Sanitary drainage
• Vent systems
Key Deliverables
Key Deliverables Structural BIM Modeling
✔ Full coordinated MEPF Revit model<br>
✔ Clash-free installation drawings<br>
✔ Navisworks clash reports<br>
✔ Utility coordination layouts<br>
✔ Cleanroom-compliant routing strategy<br>
✔ Construction-ready coordinated model
Value Delivered to Client
Value Delivered
✅ Zero installation conflicts on site<br>
✅ Optimized utility routing in constrained zones<br>
✅ Improved installation speed<br>
✅ Reduced RFIs and rework<br>
✅ Cleanroom-compliant engineering delivery
Project Metrics
Project Metrics
|
Metric
|
Result
|
|---|---|
|
Disciplines
|
4
|
|
Coordination
|
Full MEPF
|
|
Facility Type
|
Industrial Manufacturing
|
|
Environment
|
Cleanroom
|
|
Site Conflicts
|
Zero Installation Clashes
|
Project Details
Project Type:
Precision Electronics Manufacturing Facility
Sector:
Industrial / Semiconductor / Electronics Manufacturing
BIM Scope:
Full Integrated MEPF Coordination
Platform:
Autodesk Revit + Autodesk Navisworks
Disciplines Covered:
4 (HVAC, Electrical, Fire Fighting, Plumbing)
BIM Scope:
Complete Structural BIM Modeling & Drafting
Facility Type:
Cleanroom Manufacturing Environment
Project Client Outcome
Strategic Value for Industrial / Manufacturing Pitch
We delivered full MEPF coordination for a precision electronics manufacturing facility, including cleanroom-compliant HVAC, electrical, plumbing, and fire systems—with zero installation clashes. Ideal capability for industrial, semiconductor, and high-tech manufacturing projects.
